Product Details
Download Brochure- Useable on front or rear of a tractor
- Quickly converts tractor to turf maintenance
- 2-year warranty
- Adjustable cutting depth
| PART NUMBER | 403510 | 403515 | 403520 | 403525 |
| MODEL | 4" | 5" | 6" | 7" |
| OVERALL WIDTH | 52" | 65" | 76" | 89" |
| WORKING WIDTH | 48" | 60" | 72" | 84" |
| TRACTOR HP RANGE | 20-50 HP | 25-50 HP | 30-50 HP | 35-50 HP |
| CUTTING HEIGHT | 1"-4" | 1"-4" | 1"-4" | 1"-4" |
| 3-POINT HITCH TYPE | Category 1 | Category 1 | Category 1 | Category 1 |
| NUMBER OF BLADES | 3 | 3 | 3 | 3 |
| PTO INPUT SPEED | 540 RPM | 540 RPM | 540 RPM | 540 RPM |
| DECK THICKNESS | 7 Gauge | 7 Gauge | 7 Gauge | 7 Gauge |
| PTO SHAFT TYPE | Series 4 | Series 4 | Series 4 | Series 4 |
| BELTS | 2 | 2 | 2 | 2 |
| FRONT ROLLER | Standard | Standard | Standard | Standard |
| WEIGHT (WITHOUT PTO) | 450 lbs | 400 lbs | 554 lbs | 662 lbs |
| HEAVY DUTY | ||
|---|---|---|
| HEAVY DUTYPART NUMBER | 403740 | 403750 |
| HEAVY DUTYSIZE | 87" | 98" |
| HEAVY DUTYOVERALL WIDTH | 96" | 106" |
| HEAVY DUTYMOWING WIDTH | 87" | 98" |
| HEAVY DUTYTRACTOR HP RANGE | 50-100 | 50-100 |
| HEAVY DUTY3-POINT HITCH TYPE | Category 2 | Category 2 |
| HEAVY DUTYHYDRAULIC OFFSET | 15" | 15" |
| HEAVY DUTYNUMBER OF HAMMERS | 20 | 24 |
| HEAVY DUTYNUMBER OF BLADES | 60 | 72 |
| HEAVY DUTYROLLER DIAMETER | 6.69" | 6.69" |
| HEAVY DUTYROTOR DIAMETER | 6.69" | 6.69" |
| HEAVY DUTYWEIGHT W/OUT PTO | 1,726 lbs | 1,907 lbs |
| HEAVY DUTYBELTS | 4 | 5 |
